| RoHS | RoHS |
|---|---|
| Height | 3.374" (85.70mm) |
| Ratings | - |
| Shielding | Unshielded |
| Tolerance | - |
| Number of Coils | 2 |
| Size / Dimension | 3.870" L x 3.374" W (98.30mm x 85.70mm) |
| Current Rating - Series | 25 A |
| Current Rating - Parallel | 50 A |
| Current Saturation - Series | - |
| DC Resistance (DCR) - Series | 12mOhm |
| Current Saturation - Parallel | - |
| DC Resistance (DCR) - Parallel | 3mOhm |
| Inductance - Connected In Series |
| 1.2 mH |
| Inductance - Connected In Parallel | 300 µH |
|---|
