| RoHS | RoHS |
|---|---|
| Height | 2.811" (71.40mm) |
| Ratings | - |
| Shielding | Unshielded |
| Tolerance | - |
| Number of Coils | 2 |
| Size / Dimension | 3.374" L x 3.563" W (85.70mm x 90.50mm) |
| Current Rating - Series | 12 A |
| Current Rating - Parallel | 24 A |
| Current Saturation - Series | - |
| DC Resistance (DCR) - Series | 52mOhm |
| Current Saturation - Parallel | - |
| DC Resistance (DCR) - Parallel | 13mOhm |
| Inductance - Connected In Series |
| 4.8 mH |
| Inductance - Connected In Parallel | 1.2 mH |
|---|
